Label Die-cutting Machine_Machine_Flexo Label Printing Machine-Daba Machine

Home / Machine / Label Die-cutting Machine /

Label Die-cutting Machine

DABA Machinery's intermittent label die-cutting machine is a high-precision and high-efficiency device specially designed for post-press processing of label printing. It is suitable for die-cutting needs of multiple categories including self-adhesive labels, anti-counterfeiting labels and electronic identification labels, and is widely used in food, pharmaceutical, electronics, daily chemical and other industries.

Main features of Label Die-Cutting Machine

Equipped with a full servo drive system, the machine achieves a die-cutting accuracy error of ≤0.02mm, which can precisely meet the forming requirements of high-precision labels. It integrates integrated die-cutting, waste removal and rewinding functions, eliminating the need for additional auxiliary equipment, greatly simplifying the production process and improving workshop space utilization. In response to the industry characteristics of "small-batch and multi-variety" label printing, it adopts a quick job change design with a fast-locking device for die-cutting rollers, reducing job change time by more than 30% and effectively cutting down downtime losses.

In terms of material compatibility, the machine supports various label substrates such as coated paper, PET, PVC and fragile paper. By intelligently adjusting roller pressure, it avoids problems like thin material stretching and thick material indentation. Meanwhile, the machine incorporates a user-friendly operation interface with built-in preset modes for various die-cutting parameters, enabling ordinary workers to master the operation after simple training and lowering the enterprise's employment threshold.

In terms of quality, core components have undergone rigorous wear-resistance and pressure-resistance tests, with a service life 1.5 times the industry average. The whole machine complies with the ISO9001 quality management system standards, and core configurations have passed CE certification, meeting the access requirements of the international market.

In terms of services, full-life-cycle technical support is provided, including equipment installation and commissioning, operation training, spare parts supply, etc. Domestic customers receive a 24-hour response, while international customers get technical support within 48 hours, ensuring the stable operation of the equipment.

High-Precision Intermittent Rotary Die Cutting Machine With Slitting Rewinding for Label Paper

Brand Name : DABA

Model Number : DBMQ-370B

Slitting Speed ：200m/min

Die Cutting Speed : 200m/min

Max Web Width : 370 mm

Max Unwinding Diameter : 700 mm

Max Rewinding Diameter : 700 mm

Die cutting length : 178~470 mm (7'~18.5')

Overall Diameter : 2100 *1100 *1500 mm

Voltage : 380V

weight : 2000 kg

DABA Servo IML Label Rotary Die Cutting Machine In-Mold Label Die Cutter for Self Adhesive Paper Film Sticker

Brand Name : DABA

Model Number : DBMQ-370PLUS

Max.Web Width : 370mm

Application Material Thickness : 30um-300um

Max. Rotary Die Cutting Width : 370 mm

Max Unwinding Diameter : 800 mm

Max Rewinding Diameter : 800 mm

Max. Full Rotary Die Cutting Speed : 120m/min

dimension(l*w*h) : 1300*1000*1600mm

Machine Weight : 1500 kg

DABA High Efficiency Blank Label Slitting Die Cutting Machine With Two Die-Cutting Stations

Brand Name : DABA

Model Number : DBFQ-320B

Max.web width(mm) ：Up to 320mm

Max.unwinding diameter(mm) ：500

Die Cutting Speed ： 120m/min

Slitting Speed： 120m/min

Die cutting length：178-470mm (7" - 18,5")

Max.rewinding diameter(mm)：480/220mm

Weight (KG) ：1200

Overall Diameter : 1800*1100*1500mm

DABA 320mm Automatic Rotary IML Label Flatbed Die-Cutting Machine Roll to Roll Paper Cutting Machine

Brand Name : DABA

Model Number : DBMQ-320A

Max.web width(mm) ：320

Max.unwinding diameter(mm) ：600

Independent Unwinding(mm) ： 1000

Unwinding tension control ： Friction plate brake

Die-cutting range(mm) ：300*350

Max. die-cuttingspeed：200m/min

Max.rewinding diameter(mm)：600

Weight (KG) ：1000

Dimension(l*w*h) : 1300*1000*1600mm

Hot Stamping Flatbed Die-cutting Machine Machine Station for Label Paper Packaging

Brand Name : DABA

Model Number : DBMQ-320A

Max.web width(mm) ：320

Max.unwinding diameter(mm) ：600

Independent Unwinding(mm) ： 1000

Unwinding tension control ： Friction plate brake

Die-cutting range(mm) ：300*350

Max. die-cuttingspeed：200m/min

Max.rewinding diameter(mm)：600

Weight (KG) ：1000

Dimension(l*w*h) : 1300*1000*1600mm

DABA Servo Driven Intermittent Rotary Die Cutting Machine With Slitting Rewinding for BOPP Film Label Paper

Brand Name : DABA

Model Number : DBMQ-370B

Slitting Speed : 200m/min

Die Cutting Speed : 200m/min

Max Web Width : 370 mm

Max Unwinding Diameter : 700 mm

Max Rewinding Diameter : 700 mm

Die cutting length : 178~470 mm (7'~18.5')

Overall Diameter : 2100*1100*1500 mm

Machine Weight : 2000 kg

Power Supply : 380V / 220V / 50HZ

Accuracy ： ± 0.10 mm

High Speed 370mm Full Rotary Die Cutting Machine 200mmin for Blank Label

Brand Name : DABA

Model Number : DBMQ-370B

Max. Web Width : 370mm

Max. Die cutting width : 350mm

Max. Slitting width : 20mm

Max. Die cutting speed : 200m/min (water based label material)

Max. Unwinding Dia. : 800mm

Max. Up turret Rewinding Dia. : 450mm

Max. Downing rewinding Dia. : 800mm

Machine Size (L * W * H) : 2100*1100*1500mm

weight : 1000kg

Full Rotary Die Cutting Machine With 4 Shaft Turret Rewinding Machine for Self-adhesive Label Production Line

Brand Name : DABA

Model Number : DBMQ-370

Die Cutting Speed : 200m/min

Max Web Width : 370mm

Max. Die Cutting Width : 360mm

Max Unwinding Diameter : 700mm

Max Rewinding Diameter : 700mm

Die cutting length: 178~470 mm (7'~18.5')

Dimension(l*w*h) : 1300*1000*1600mm

Kiss-Cut Precision Accuracy : ±0.10mm

Usage : Paper Printer, Label Printer, Card Printer, Tube Printer, Bill

Rating Voltage & Current : 380V 50Hz 50A

weight : 1500kg

8 item
1

DABA Label Die-Cutting Machine Purchase: Expert Answers Directly from the Manufacturer

As an experienced label die-cutting machine manufacturer, DABA understands that investing in new equipment requires careful consideration. Here, we address key questions international buyers frequently ask about our machines, capabilities, customization options, and support services—helping you make an informed decision.

What types of labels and substrates are compatible with DABA's label die-cutting machines?

It is suitable for die-cutting of various labels such as self-adhesive labels, anti-counterfeiting labels, electronic identification labels, and food/pharmaceutical packaging labels. Compatible substrates include coated paper, PET, PVC, PP, PE, fragile paper, thermal paper, and degradable materials, with a thickness adaptation range of 80g/m²-350g/m², covering most industry application needs.

How to choose the right label die-cutting machine for small-batch vs. large-batch production?

For small-batch and multi-variety production, we recommend the intermittent label die-cutting machine with quick job change design, which can shorten job change time by more than 30% and adapt to frequent variety switching. For large-batch and high-speed production, the high-speed continuous die-cutting machine is preferred, with a maximum die-cutting speed of up to 350m/min, ensuring efficient and stable mass production.

Can the equipment adapt to special die-cutting requirements such as irregular shapes or ultra-small labels?

Yes! We provide customized die-cutting roller solutions for irregular shapes (such as oval, special-shaped logos) and ultra-small labels (minimum size ≥10mm×15mm). Equipped with high-precision positioning system, it can ensure the accuracy of special-shaped die-cutting, with a die-cutting error ≤0.02mm, meeting the needs of high-end customized labels.

What is the die-cutting accuracy of the equipment, and how to ensure stable accuracy during long-term operation?

The equipment adopts a full-servo drive system and high-precision ball screw guide rail, with a die-cutting accuracy error ≤0.02mm. During long-term operation, the intelligent pressure compensation system and real-time deviation correction function can automatically adjust parameters to avoid accuracy deviation caused by mechanical wear or substrate tension changes, ensuring consistent die-cutting quality of batch products.

Is the job change process of the die-cutting machine complicated? How long does it take for a single job change?

The job change process is simple and efficient. It is equipped with a quick-locking device for die-cutting rollers and a parameter memory function. For conventional label specifications, the job change can be completed in 10-15 minutes (including roller replacement and parameter adjustment), which is 30% faster than traditional models, effectively reducing downtime loss.

How to solve the problems of substrate stretching, tearing or incomplete die-cutting during operation?

First, the intelligent tension control system can be used to adjust the substrate tension according to different materials to avoid stretching or tearing. Second, for incomplete die-cutting, the die-cutting pressure can be precisely adjusted through the touch screen; if the problem persists, check whether the die-cutting knife is blunt and replace it in time. In addition, our technical team can provide remote guidance or on-site debugging services.

What are the key points of daily maintenance for the label die-cutting machine?

Daily maintenance mainly includes three aspects: 1) Clean the die-cutting roller, waste removal system and guide roller regularly to avoid residue accumulation affecting die-cutting effect; 2) Add lubricating oil to the servo motor, transmission chain and other moving parts on schedule according to the maintenance manual to ensure smooth operation; 3) Check the wear of the die-cutting knife and pressure roller regularly, and replace worn parts in time. We will provide a detailed maintenance manual and operation training.

What is the service life of the core components of the equipment, and is there any after-sales support for spare parts?

Core components such as servo motors, die-cutting rollers and precision bearings have undergone rigorous wear-resistant and pressure-resistant tests, with a service life 1.5 times the industry average. We have established spare parts warehouses at home and abroad: international customers can get spare parts supply response within 48-72 hours through overseas service outlets.

Does the label die-cutting machine meet international market compliance standards?

Yes! The whole machine has passed ISO9001 quality management system certification and CE certification. The core materials are in line with EU food contact material standards (EC 1935/2004) and US FDA standards, which can meet the safety and environmental protection access requirements of different countries and regions, and support global export and use.

Do you provide installation, commissioning and operation training after purchasing the equipment?

We provide full-life-cycle service support. After equipment delivery, professional technicians will be dispatched to the site for installation and commissioning to ensure the equipment reaches the optimal operating state. At the same time, systematic "theoretical + practical" training will be provided for operators, covering equipment operation, parameter setting, fault diagnosis and daily maintenance, until the team can operate independently.

Can customized solutions be provided for special working environments or special process requirements?

Yes! We can provide personalized customization according to customer needs. For example, optimize the equipment's heat dissipation and dustproof system for high-temperature, high-humidity or dusty workshops; add special functional modules such as online quality inspection and automatic waste collection for customers with special process requirements; and adjust the equipment's structure and parameters according to special substrate characteristics to ensure perfect adaptation to the customer's production scenario.

Why choose DABA as your supplier for flexographic label printing machines?

01. Raw Materials & Component Quality: Laying a Solid Foundation for Quality from the Source

DABA adheres to the principle of global selection + independent strict control, with core components all sourced from world-leading brands to ensure long-term stability and high performance of the equipment.

01.Electrical Control System：
• Main Motor: Siemens/Yaskawa servo motors from Germany/Japan, high speed regulation precision
• PLC: Siemens/Mitsubishi, fast response and strong anti-interference ability
• Sensors: Swiss/Japanese brands, registration accuracy ≤ ± 0.02mm

02.Printing Core Components：
• Printing Unit: Independent drive design, each unit can be adjusted separately for fast job changeover
• Ink Circuit System: Closed-loop circulation design, avoiding pigment precipitation and ensuring uniform color

03.Raw Material Access Standard：
100% incoming inspection for key components; suppliers must pass SGS/CE certification; a qualified supplier list is established and reviewed regularly

02. Manufacturing Process: Precision Intelligent Manufacturing, Balancing Efficiency and Accuracy

With modular design + digital production as the core, we ensure the process precision and delivery efficiency of each machine.

Precision Machining：
01.Key structural parts are processed by CNC machining centers with a tolerance control of ± 0.005mm to guarantee assembly precision.
02.The whole machine undergoes dynamic balance testing, with noise below 75dB during high-speed operation, improving stability by 40%.

Intelligent Assembly：
01.Modular assembly process shortens job changeover time by 50%, supporting quick installation of optional modules such as hot stamping and laminating.
02.Visual traceability throughout the assembly process; 100% code scanning record for key procedures, facilitating after-sales service and quality control.

Green Technology：
01.Water-based ink/UV solvent-free printing technology, complying with EU REACH and US FDA environmental standards.
02.Energy consumption is 20% lower than similar products in the industry, reducing long-term operating costs.

03. Quality Control: Full-cycle Closed Loop, Complying with International Standards

A six-level quality inspection system is established, covering R&D, production and delivery, to ensure the equipment meets global market access requirements.

01.R&D Verification:
• New products undergo 5,000 hours of trouble-free testing, simulating extreme working conditions (high temperature, high humidity, continuous load).
• Key technologies have obtained a number of patents, such as automatic registration and fault self-diagnosis algorithms, improving operational convenience.

02.Production Inspection:
• First Article Inspection: Full performance test is conducted on the first machine of each batch; mass production can only be carried out after passing the test..
• In-process Inspection: Quality inspection points are set for key procedures such as frame welding and electrical wiring, with the defect rate controlled within 0.1%.

03.Final Factory Inspection:
• Full Performance Test: Continuous printing for 8 hours to test registration accuracy, speed stability, reject rate and other indicators.
• International Certification: Each machine is provided with CE/SGS certification reports, meeting compliance requirements in the EU, Southeast Asia and other regions.

04.After-sales Traceability:
• Each machine has a unique serial number, supporting full-link traceability of production, installation and maintenance, to quickly locate problems.

04. Customized Service: In-depth Adaptation to Foreign Trade and Production Needs

Based on foreign trade and multi-industry scenarios, we provide on-demand customization + localized support to help customers expand the market quickly.

01.Equipment Customization:
•Customized for target markets: such as high-temperature and moisture-resistant models for Southeast Asia, sterile label production lines for the European pharmaceutical industry.
• Optional module installation according to process requirements: hot stamping, laminating, die-cutting, variable data printing and other modules, no need for additional procurement.
• Customized according to production capacity: high-speed lines (300m/min) and medium-speed lines (150–200m/min), adapting to different order scales.

02.Localization Adaptation:
• Multi-language operation interface (English, Spanish, Arabic, Russian, etc.) is provided to adapt to the operation of overseas employees.
• Assist customers in completing local certifications (such as UL, CSA) to shorten the market access cycle.

03.Solution Customization:
• Combined with customer products (paper cups/paper boxes/paper bowls, etc.), provide integrated "equipment + consumables + process" solutions.
• Connect with ERP system to realize automatic entry of variable data, adapting to small-batch and multi-batch orders.

05. Packaging & Transportation: Safe Protection, Global Damage-free Delivery

According to the characteristics of cross-border transportation, multi-layer protection + professional logistics are adopted to ensure the equipment is delivered to customers in good condition.

01.Professional Packaging:
•Inner Layer: Anti-rust film + foam buffer, key components are reinforced separately.
• Outer Layer: Export-grade fumigated solid wood pallets + high-strength corrugated cartons, moisture-proof and shock-proof.
• Clear Marking: Including shipping marks, center of gravity and fragile labels, complying with international transportation standards.

02.Transportation Guarantee:
• Cooperate with world-renowned logistics companies (DHL, Maersk, etc.) to provide door-to-door service.
• Full freight insurance is purchased, with the transportation damage rate less than 0.5% and fast claim settlement.

03.Arrival Assistance:
• Provide detailed unpacking lists and installation guides, supporting remote guidance for unpacking.
• Overseas customers can coordinate with local cooperative service providers for on-site assistance, reducing installation delays.

06. After-sales Service: Global Response, Solving Foreign Trade After-sales Pain Points

A 7×24-hour full-process service system is built to open up the rapid response channel of "remote + on-site + spare parts".

01.Response Time:
•Remote Support: 7×24-hour online, problem response ≤ 15 minutes, common faults can be eliminated within 1 hour.
• On-site Service: On-site service within 72 hours in core markets, 5–7 working days in other regions.

02.Warranty & Training:
• 1-year warranty for the whole machine, 2-year extended warranty for core components (motor, PLC), and lifelong maintenance.
• Free installation, commissioning and operation training are provided; special training for overseas employees can be customized.

03.Spare Parts Supply:
• Global spare parts centers with sufficient inventory of commonly used spare parts, delivery time ≤ 48 hours.
• Spare parts kits are provided to reduce downtime waiting time.

04.Value-added Services:
•Regular return visits are conducted to provide equipment maintenance suggestions and extend service life.
• Free software upgrades are provided to adapt to new printing standards and process requirements.

Our flexographic label printing machines can produce
for a wide range of materials and applications.

For over a decade, Daba Machinery has been deeply committed to the niche field of label printing, offering full-scenario coverage that balances standardization with customization.The main applications include:Beverage labels，Foodl Labels，Medical Labels，Cosmetic Labels，Wine bottle labels，Logistics and express labels，Daily necessities label，Hanger Tags，Barcodes & Stickers，etc.

Beverage Labels

Food Labels

Medical Product Labels

Cosmetic Labels

Bottle Labels

Logistics And Express Delivery Labels

Daily Necessities Label

Hanger Tags

DABA Flexographic Label Printing Machine Worry-Free After-Sales Service

Seamless Setup & Training

Clear Installation Guides: Simple parts come with easy-to-follow video instructions. For complex ones, our on-site engineers handle installation and training. We even have local technical teams in various countries for prompt, top-notch service.

Prepared for Anything

Advanced spare parts: We know what components are prone to wear or misuse, so we send them with your machine.Minimize downtime: Even if an error occurs, we’ll send replacement parts before you return the broken ones.

Worry-free after-sales service

Minimum 1-year warranty: All machines are covered for at least a year, some even for 2. Free parts replacement: We cover damaged parts within warranty (excluding human error), including shipping costs. Fast replacements: Send us video/photo proof of a damaged part, and we’ll ship a replacement ASAP.
